Setting Up the Monitor
To set up the monitor, ensure that the power is turned off to the monitor, computer system, and other
attached devices, then follow the instructions below.
Installing the Monitor Pedestal Base
NOTE: Do not install the pedestal base if the monitor will be used on a wall, swing arm, or other
mounting fixture; instead refer to Mounting the Monitor on page 12 in this chapter.
Place the base on a desktop or table and push the neck on the base down to its lowest position. Slide the
monitor all the way onto the base so that the Quick Release mechanism emits an audible click and is
locked in place.
CAUTION: Do not touch the surface of the LCD panel. Pressure on the panel may cause non-
uniformity of color or disorientation of the liquid crystals. If this occurs the screen will not recover
to its normal condition.
Figure 3-1 Inserting the Monitor into the Pedestal Base
Chapter 3 Setting Up the Monitor ENWW 4
