Technical Specifications
Factory Preset Display Modes (Continued)
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
6 800 x 600 48.1 72.0
7 800 x 600 46.9 75.0
8 832 x 624 49.7 75.0
9 1024 x 768 48.4 60.0
10 1024 x 768 56.5 70.0
11 1024 x 768 60.0 75.0
12 1152 x 870 68.7 75.0
13 1152 x 900 71.7 76.0
14 1280 x 1024 64.0 60.0
15 1280 x 1024 80.0 75.0
Entering User Modes
The video controller signal may occasionally call for a mode that
is not preset if:
■ You are not using a standard graphics adapter.
■ You are not using a preset mode.
If this occurs, you may need to readjust the parameters of the
monitor screen by using the on-screen display. Your changes can
be made to any or all of these modes and saved in memory. The
monitor automatically stores the new setting, then recognizes the
new mode just as it does a preset mode. In addition to the 15
factory preset modes, there are four user modes that can be
entered and stored.
User Guide B–5
