Therefore, assuming the HBA is the first device on the bus, you should check that the second
terminator is placed after the last device.
Secure the drive
NOTE: The server latches and side views of your server model may not be exactly the same as
shown in the illustrations. See the server documentation.
Mounting hardware used
Ensure that you use the correct mounting rails or locating screws, as described in Attach mounting
hardware - some servers (page 8). The server used in the illustration below has a locking mechanism
to hold the tape drive in place.
1. Push the server latch down to lock the tape drive into position, as shown in the following figure.
1. Plastic rail
2. Server latch
Figure 10 Securing the drive, mounting hardware used
2. Ensure blanking plates are in place over empty bays and replace the cover on the server.
16 Installing an internal tape drive
