HP M27fw User Manual

7
3 Illustrated parts catalog
To identify the monitor major components, use this illustration and table.
M27f/M27fe/M27fw
Item Description Q’ty
1 Encore III M27f LCM P/N(Black)/Encore III M27fw LCM
P/N(White)/ Encore III M27fe LCM P/N(Black)
1
2 WH A1007H00-6P-2L/A1251-H06 #28
75mm+ACETATE W/B HF
1
3 WH FFC 30P(1.0mm)230mm(1FOLD+PRO)60V G/F
W/CONN(A15+BC)+AL HF
1
4 WH FFC 8P(0.5mm) 350mm(3FOLD)60V G/F (A8+A6)
HF
1
5 REAR SUPPORT-L(PCR-85% ABS+5% PU/JACK BLACK
(6009-0337)
1
6 REAR SUPPORT-M(PCR-85% ABS+5% PU/JACK BLACK
(6009-0337)
1
7 REAR SUPPORT-R(PCR-85% ABS+5% PU/JACK BLACK
(6009-0337)
1
8 MAC SCREW-Ml M3.0*4.0L, BLK-N, 16

HP M27fw Specifications

General

Color depth	8 bit
Color gamut	99 %
Screen shape	Flat
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Yes
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Maximum refresh rate	75 Hz
Contrast ratio (typical)	1000:1
Display diagonal (metric)	68.6 cm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800, 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HDMI version	1.4
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	23 W
Power consumption (standby)	0.5 W
Power consumption (typical)	16 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Package depth	126 mm
Package width	690 mm
Package height	430 mm
Package weight	5800 g
Tilt angle range	-5 - 25 °
Product color	Silver, White
Market positioning	Home

Weight and Dimensions

Depth (with stand)	188.2 mm
Width (with stand)	607.9 mm
Height (with stand)	437.3 mm
Depth (without stand)	34.2 mm
Height (without stand)	356 mm
Weight (without stand)	3200 g
