HP MultiSeat t100 - Thin Client User Manual

Baffle
1. Prepare the computer for disassembly (Preparation for Disassembly on page 32).
2. Remove the access panel (
Access Panel on page 32).
3. Remove the cable from the arm that extends from the side of the baffle (1).
4. Lift the baffle straight up out of the chassis (2).
Figure 5-45 Removing the baffle
To install the baffle, reverse the removal procedure.
Baffle 67

HP MultiSeat t100 - Thin Client Specifications

General

Brand	HP
Model	MultiSeat t100 - Thin Client
Category	Server
Language	English
