6–2 Maintenance and Service Guide
Removal and Replacement Procedures
6.2 Disassembly Sequence Chart
Use the chart below to determine the section number to be
referenced when removing notebook components.
Disassembly Sequence Chart
Section Description
# of Screws Removed
6.3 Preparing the Notebook for
Disassembly
Battery pack 0
6.4 Hard Drive 2 loosened to remove the
hard drive cover
4 to disassemble the
hard drive
6.5 Notebook Feet 0
6.6 Bluetooth Board 1
6.7 Memory Module 2 loosened to remove the
memory module compartment
cover
6.8 Optical Drive 1
6.9 Switch Cover 4
6.10 Power Button Board 1
6.11 Keyboard 4
6.12 Fan 3
6.13 Heat Sink 4
6.14 Processor 0
6.15 Button Board 1
