6–48 Maintenance and Service Guide
Removal and Replacement Procedures
6.21 Speaker
1. Prepare the notebook for disassembly (Section 6.3) and then
remove the following components:
a. Optical drive (Section 6.8)
b. Switch cover (Section 6.9)
c. Keyboard (Section 6.11)
d. Button board (Section 6.15)
e. Display assembly (Section 6.17)
f. Top cover (Section 6.18)
Speaker Spare Part Number Information
Speaker 393563-001
To Next Page
