5. If it is necessary to replace the raw display panel, remove the four Phillips screws (1) that secure
the display panel to the display enclosure, and then lift the panel (2) to remove it.
6. Remove the tape (1) covering the display panel connector, disconnect the connector (2) from the display
panel, and then remove the panel (3).
7. If it is necessary to replace the camera module:
CAUTION: Handle the module with caution. This module has a thin prole and is susceptible to damage
when not handled carefully.
a. Lift up the camera module and cable (1).
Component replacement procedures 67
