HP Pavilion 14 Sleekbook User Manual

Battery
Description Spare part number
4 cell, 37 Whr, 2.55 Ah Li-ion battery 695192-001
Before disassembling the computer, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
Remove the battery:
1. Turn the computer upside down on a flat surface.
2. Slide the battery release lock (1) far enough that it rests in the unlocked position.
3. Slide the battery release latch (2) to release the battery.
4. Slide the battery (3) from the middle to remove it from the computer.
To insert the battery, follow these steps:
CAUTION: Do not slant the battery as you insert it.
1. Holding the battery in the middle, slide the battery (1) straight into the computer until the battery
release latch locks into place.
34 Chapter 4 Removal and replacement procedures

HP Pavilion 14 Sleekbook Specifications

General

Display Size	14 inches
Operating System	Windows 8
Weight	1.8 kg
Display Resolution	1366 x 768 pixels
Battery	4-cell Li-Ion
Wireless	802.11b/g/n
RAM	4 GB
Storage	500GB HDD
Graphics	Integrated Intel HD Graphics or AMD Radeon HD Graphics
Dimensions	2.1 cm
Ports	2 x USB 3.0, 1 x USB 2.0, HDMI, RJ-45, headphone/microphone combo
Processor	AMD A4 or AMD A6
