HP Pavilion 14 Sleekbook User Manual

4. Remove the battery (see Battery on page 34).
5. Remove the keyboard (see
Keyboard on page 38).
6. Remove the top cover (see
Top cover on page 42).
7. Remove the hard drive (see
Hard drive on page 46).
8. Remove the USB board (see
USB board/audio jack on page 49).
9. Remove the WLAN (see
WLAN module on page 50).
10. Remove the system board (see
System board on page 53).
Remove the speaker assembly:
NOTE: The speaker screws were removed during the process to remove the top cover.
1. Gently release the wires (1) routed along the top of the base enclosure.
2. Lift both pieces of the speaker assembly (2).
Reverse this procedure to install the speaker assembly on the base enclosure.
RJ-45 cover
Description Spare part number
RJ-45 cover 700428-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement.
Before removing the RJ-45 cover, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
Component replacement procedures 69

HP Pavilion 14 Sleekbook Specifications

General

Display Size	14 inches
Operating System	Windows 8
Weight	1.8 kg
Display Resolution	1366 x 768 pixels
Battery	4-cell Li-Ion
Wireless	802.11b/g/n
RAM	4 GB
Storage	500GB HDD
Graphics	Integrated Intel HD Graphics or AMD Radeon HD Graphics
Dimensions	2.1 cm
Ports	2 x USB 3.0, 1 x USB 2.0, HDMI, RJ-45, headphone/microphone combo
Processor	AMD A4 or AMD A6
