System board
NOTE: The system board spare part kit includes replacement thermal materials.
Description Spare part
number
System board (includes replacement thermal materials):
All system boards use the following part numbers:
xxxxxx-001: Without the Windows operating system
xxxxxx-501: Windows 8.1 Standard
●
AMD A4-6210 UMA LVDS (1.8 GHz), 1600 MHz/2 MB L2, quad core 15 W 809397-xxx
●
AMD A6-6310 UMA LVDS (1.8 GHz, up to 2.4 GHz), 1600 MHz/2 MB L2, quad core 15 W 809398-xxx
●
AMD A8-7410 UMA LVDS (2.2 GHz, SC turbo up to 2.5 GHz), Max 1600 MHz/2 MB L2, quad core 15 W 809399–xxx
●
AMD A10-8700P LVDS (1.8 GHz, SC turbo up to 3.2 GHz), Max1600 MHz/2 MB L2, quad core 15 W 809400—xxx
●
AMD A10-8700P (1.8 GHz, SC turbo up to 3.2 GHz), Max1600 MHz/2 MB L2, quad core 15 W eDP 809402–xxx
For use in models with discrete graphics (AMD R7 M360 (Meso-XT)):
●
AMD A8-7410 discrete R7M360 LVDS (2.2 GHz, SC turbo up to 2.5 GHz), Max 1600 MHz/2 GB L2, quad core 15
W
809401-xxx
●
AMD A8-7410 discrete R7M360 LVDS (2.2 GHz, SC turbo up to 2.5 GHz), Max 1600 MHz/2 GB L2, quad core 15
W eDP
810937–xxx
●
AMD A10-8700P R7M360 (1.8 GHz, SC turbo up to 3.2 GHz), Max1600 MHz/2 MB L2, quad core 15 W eDP 809403–xxx
●
AMD A10-8700P R7M360 (1.8 GHz, SC turbo up to 3.2 GHz), Max1600 MHz/2 MB L2, quad core 15 W LVDS 810936–xxx
Before removing the system board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 27).
5. Remove the optical drive (see
Optical drive on page 28).
6. Remove the bottom cover (see
Bottom cover on page 32).
NOTE: When replacing the system board, be sure that the following components are removed from the
defective system board and installed on the replacement system board:
●
Memory modules (see
Memory module on page 41)
●
WLAN module (see
WLAN module on page 37)
●
Heat sink assembly (see
Heat sink assembly on page 43)
●
Fan (see
Fan on page 42)
To remove the system board:
48 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
