Display assembly, touch

Component Spare part number

Display bezel (includes screw covers) 809291-001

Touch screen connector board spared with the display panel

Webcam/microphone module touch screen 810961-001

Raw display panel (16:9 Ultra Wide Aspect Ratio [43.9-cm 17.3-in]; includes screw covers)

Antiglare HD+ touch screen 809300-001

Antiglare FHD+ touch screen 809301-001

Panel Bracket (included with the Display Panel touch screen)

Display cable FHD touch screen (includes screw covers) 809294-001

Display cable HD touch screen (includes screw covers) 809932-001

Antennas touch screen (includes wireless antenna cables and transceivers; includes screw covers) 809272-001

Hinges touch screen (left and right, includes screw covers) 809299-001

Display enclosure:

Cobalt blue models touch screen 809281-001

Sunset red models touch screen 809280-001

Blizzard white models touch screen 809284-001

Natural silver models touch screen 809279-001

Violet purple models touch screen 809283-001

Peachy pink models touch screen 809282-001

Sparkling black models for use with touch screen 810948-001

Before removing the display assembly, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 27).

5. Remove the optical drive (see

Optical drive on page 28).

6. Remove the bottom cover (see

Bottom cover on page 32).

To remove the display assembly:

1. Position the computer on its side, partially open.

2. Remove the four Phillips PM2.5×5.0 screws (1) that secure the display assembly to the computer.

3. Open the display to rotate the hinges upward to an angle (2).

62 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
