HP Pavilion 17 User Manual

Hard drive
Description Spare part number
1 TB, 5400 rpm, 9.5 mm 778192-005
750 GB, 5400 rpm, 9.5 mm available for Windows 8.1 and Windows 7 778190-005
500 GB 5400 rpm 9.5 mm available for Windows 8.1 and Windows 7 778188-005
500 GB 5400 rpm 7 mm hybrid 732000-005
1 TB, 5400 rpm 9.5 mm available for Windows 8.1 and Windows 7 731999-005
750 GB 5400 rpm + 8 GB NAND hybrid, 9.5 mm 732001-005
500 GB 5400 rpm + 8 GB NAND hybrid, 7 mm 732000-005
1.5 TB, 5400 rpm 9.5 mm for HP Pavilion 15 Notebooks and AMD computers only 747375-005
Hard Drive Hardware Kit, for HP Pavilion 17 Notebook PC 773501-001
Hard Drive Hardware Kit, for HP Pavilion 15 Notebook PC 762504-001
Hard Drive Hardware Kit, for HP Pavilion 15 Notebook PC in natural silver 763100-001
Hard Drive Hardware Kit, for HP Pavilion 15 Notebook PC in snow white 763101-001
Hard Drive Hardware Kit, for HP Pavilion 15 Notebook PC in aqua blue 763103-001
Hard Drive Hardware Kit, for HP Pavilion 15 Notebook PC in vibrant red 763102-001
Hard Drive Hardware Kit, for HP Pavilion 15 Notebook PC in neon purple 778265-001
Hard Drive Hardware Kit, for HP Pavilion 15 Notebook PC in for Beats Audio 767516-001
Hardware sleeve for HP Pavilion 17 Notebook PC 777944-001
Hardware sleeve for HP Pavilion 15 Notebook PC 776506-001
Before removing the hard drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 76).
5. Remove the optical drive.
6. Remove the base enclosure and top cover (see
Base enclosure on page 80).
7. Remove the USB connector cable (see
USB board on page 104).
Remove the primary hard drive:
▲
Disconnect the hard drive cable from the system board (1), and then tilt the hard drive (2) and lift
to remove it (3).
Component replacement procedures 105

HP Pavilion 17 Specifications

General

Bus type	DMI
Stepping	L1
Tjunction	90 °C
Processor cache	3 MB
Processor cores	2
Processor model	i3-3110M
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-3100 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	24
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel HM76 Express
Memory slots	2x SO-DIMM
Internal memory	6 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 2 + 1 x 4 GB
HDD size	2.5 \
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Number of SSDs installed	0
Display surface	Gloss
Display diagonal	17.3 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Disc types supported	CD, DVD
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card memory	1.65 GB
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1000 MHz
Audio system	DTS Sound+
Front camera resolution	1280 x 720 pixels
WWAN	Not installed
Data network	Not supported
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Keyboard layout	-
Pointing device	Touchpad
Operating system installed	Windows 8
Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Country of origin	China
Processor code	SR0N2
Processor ARK ID	65700
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery life (max)	- h
Number of battery cells	6
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.42 A
AC adapter output voltage	19 V
Cables included	AC
Operating altitude	0 - 3050 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 85 %
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	267 mm
Width	420 mm
Height	32.8 mm
Weight	2900 g
