Maintenance and Service Guide 7–1
7
Screw listing
This section provides specification and reference information for the screws used in the computer. The screws
listed in this section are available in the Screw Kit, spare part number 496890-001.
Phillips PM2.0×6.0 captive screw
Where used: 3 captive screws that secure the hard drive cover to the computer (screws are secured by C-clips)
Color Quantity Length Thread Head diameter
Black 3 6.0 mm 2.0 mm 5.0 mm
