3–18 Maintenance and Service Guide
Illustrated parts catalog
Touch screen display assembly subcomponents
Description Spare part number
(1) Display bezel:
For use only with dv3-2300 models with blue trim and 13.3-inch touch screen displays 593022-001
For use only with dv3-2000 computer models with 13.3-inch touch screen displays 595179-001
For use only with dv3-2000 computer models with 13.4-inch touch screen displays 595180-001
(2) Display hinges for use only with dv3-2000 computer models
For use only with computer models with 13.3-inch touch screen display assemblies 595178-001
For use only with computer models with 13.4-inch touch screen display assemblies 577679-001
(3) Display panel cable (includes webcam/microphone module cable) 577681-001
(4) Wireless antenna set 531781-001
(5) Webcam/microphone module 531785-001
(6) Display enclosure 578111-001
✎
Spare part kits are not available for the display panel. If this component must be replaced, the entire display assembly
must be replaced.
