Removal and Replacement Procedures
Maintenance and Service Guide 5–3
5.2 Disassembly Sequence Chart
Use the chart below to determine the section number to be
referenced when removing computer components.
Disassembly Sequence Chart
Section Description
# of Screws Removed
5.3 Preparing the Computer For
Disassembly
Battery 0
5.4 Hard Drive 2 loosened to remove the hard
drive cover
6 removed to disassemble the
hard drive
5.5 Computer Feet 0
5.6 Memory Module 2 loosened to remove the
memory module compartment
cover
5.7 RTC Battery 0
5.8 Mini Card Module 2
Ä
To prevent an unresponsive system and the display of a
warning message, install only a Mini Card device
authorized for use in your computer by the governmental
agency that regulates wireless devices in your country or
region. If you install a device and then receive a warning
message, remove the device to restore computer
functionality. Then contact technical support by selecting
Start > Help and Support > Contact support.
5.9 Optical Drive 1 to remove the optical drive
2 to remove the optical drive
bracket
5.10 Switch Cover 3
5.11 Keyboard 4
