Removal and Replacement Procedures
Maintenance and Service Guide 5–23
5.10 Switch Cover
1. Prepare the computer for disassembly (Section 5.3).
2. Close the computer.
3. Turn the computer upside down with the front panel
toward you.
4. Remove the three Phillips PM2.5×5.0 screws that secure
the switch cover to the computer.
Removing the Switch Cover Screws
Switch Cover Spare Part Number Information
For use with full-featured computer models
For use with defeatured computer models
431423-001
431422-001
