Page #129 background imageLoading...
Page #129 background image
on the drivers and software installed on your computer, you may need slightly more than 8 GB of
space. HP recommends that you use a 16 GB device or above for best results.
IMPORTANT: Remember to insert your USB device into the USB port on the computer before starting
this procedure.
To create the restore image:
1. Click the System menu icon at the far right of the top panel, and then click System Settings
> Backup.
2. Select Storage from the panel on the left side of the window, click the down-arrow next to
Backup location, and select the USB device from the drop-down list.
NOTE: If the USB device is not listed in the drop-down list for Backup Location, select Local
Folder, and then click the Choose Folder button. Select the USB device from the panel on the
left side of the Choose Folder window, and click OK.
3. Select Overview from the panel on the left side of the window, and then click Backup Now.
4. Follow the on-screen instructions.
Performing recovery using the restore DVD
NOTE: The following procedure uses the F11 BIOS Recovery feature to perform the recovery.
1. If possible, back up all personal files.
2. Shut down the computer.
3. Be sure the restore DVD or USB device is connected to the computer.
4. Restart the computer.
5. Using the arrow keys, select Recovery, and then press enter.
6. Follow the on-screen instructions.
NOTE: If you are unable to boot (start up) your computer, and you did not create a system recovery
disc, you must purchase an Ubuntu Operating System DVD to reinstall the operating system. For
additional information, refer to the Worldwide Telephone Numbers booklet.
Backing up your information
You should back up your computer files on a regular schedule to maintain a current backup. You can
manually back up your information to an optional external drive, a network drive, discs, or the Ubuntu
One website. Back up your system at the following times:
At regularly scheduled times
Before the computer is repaired or restored
Before you add or modify hardware or software
To back up your home directory files to the Ubuntu One website using the Deja Dup Backup Tool:
Backing up your information
119

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Pavilion TouchSmart 15 and is the answer not in the manual?

HP Pavilion TouchSmart 15 Specifications

General IconGeneral
Processor cache1 MB
Processor cores2
Processor familyAMD A4
Processor socketSocket FP2 (µBGA-827)
Processor frequency1.9 GHz
Processor cache typeL2
Processor manufacturerAMD
Processor boost frequency2.4 GHz
Motherboard chipsetAMD A70M
Memory slots2x SO-DIMM
Internal memory4 GB
Memory form factorSO-DIMM
Internal memory typeDDR3-SDRAM
Maximum internal memory8 GB
Memory layout (slots x size)1 x 4 GB
LightScribeNo
AC adapter includedYes
HDD speed5400 RPM
SSD capacity0 GB
HDD interfaceSATA
Storage mediaHDD
Total storage capacity1000 GB
Compatible memory cardsMMC, SD, SDHC, SDXC
Number of HDDs installed1
Number of SSDs installed0
Display surfaceGloss
Display diagonal15.6 \
Touch technologyMulti-touch
Display brightness200 cd/m²
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Discrete graphics card modelNot available
Maximum graphics card memory1.98 GB
On-board graphics card modelAMD Radeon HD 7400G
On-board graphics card familyAMD Radeon HD 7000
Audio systemDolby Advanced Audio
Speakers manufacturerAltec Lansing
Front camera resolution1280 x 720 pixels
Data networkNot supported
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100Base-T(X)
Ethernet LAN data rates10, 100 Mbit/s
Charging port typeDC-in jack
Headphone connectivity3.5 mm
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Keyboard layout-
Pointing deviceTouchpad
Operating system installedWindows 8
Operating system architecture64-bit
Form factorClamshell
Product typeLaptop
Product colorBlack
Country of originChina
Battery life (max)- h
Number of battery cells4
AC adapter power65 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
Sustainability certificatesEPEAT Silver, ENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth259 mm
Width386 mm
Height24 mm
Weight2100 g
