Top cover
NOTE: The top cover spare part kit includes the TouchPad buttons, TouchPad board and TouchPad
cable.
Description Spare part number
In pearl white finish 732091-001
In flyer red finish 732092-001
In revolutionary blue finish 732093-001
In regal purple finish 732094-001
In sparkling black finish 732095-001
In aluminum metal finish 732096-001
In mineral black finish 737178-001
In Goji berry finish 737179-001
In hazel berry finish 737180-001
In raspberry finish 737181-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement
Before removing the top cover, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 43), and then remove the following components:
a. Optical drive (see
Optical drive on page 48).
b. Remove the service door (see
Service door on page 45).
c. Remove the WLAN module (see
WLAN module on page 47).
d. Remove the memory module (see
Memory module on page 45).
e. Keyboard (see
Keyboard on page 55).
Component replacement procedures
61
