Processor
NOTE: All processor spare part kits include replacement thermal material.
Description Spare part number
Intel models:
Intel Core i7 3632QM, 2.2-GHz processor with 6-MB L3 cache 701658-001
Intel Core i5 3380M, 2.9-GHz processor with 3-MB L3 cache 708762-001
Intel Core i5 3340M, 2.7-GHz processor with 3-MB L3 cache 708761-001
Intel Core i5 3230M, 2.6-GHz processor with 3-MB L3 cache 711903-001
Intel Core i3 3130M, 2.6-GHz processor with 3-MB L3 cache 713163-001
Intel Core i3 3120M, 2.5-GHz processor with 3-MB L3 cache 700627-001
Intel Pentium 2020M, 2.4-GHz, with 2-MB L3 cache 700628-001
Intel Celeron 1000M, 1.8-GHz, with 2-MB L3 cache 713162-001
AMD models:
AMD A8-5550M, 3.1-GHz/2.1-GHz, 4-MB L2 cache, HD 8550G graphics 713551-001
AMD A8-4500M, 2.8-GHz/1.9-GHz, 4-MB L2 cache, HD 7640G graphics 683048-001
AMD A6-5350M, 3.5-GHz/2.9-GHz, 1-MB L2 cache, HD 8450G graphics 713550-001
AMD A6-4400M, 3.2-GHz/2.7-GHz, 1-MB L2 cache, HD 7520G graphics 683047-001
AMD A4-5150M, 3.3-GHz/2.7-GHz, 1-MB L2 cache, HD 8350G graphics 713549-001
AMD A4-4300M, 3.0-GHz/2.5-GHz, 1-MB L2 cache, HD 7420G graphics 685990-001
Before removing the processor, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 36).
5. Remove the following components:
a. Service door (see
Service door on page 37).
b. Hard drive (see
Hard drive on page 38)
c. Optical drive (see
Optical drive on page 41)
d. WLAN/Bluetooth module (see
WLAN/Bluetooth combo card on page 45)
e. WWAN module (see
WWAN module on page 47)
f. Keyboard (see
Keyboard on page 49)
g. Top cover (see
Top cover on page 53)
76 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
