Display assembly (panel, bezel, webcam, microphone)
All display assemblies include WLAN antenna transceivers and cables. WWAN models include 2
WWAN antenna transceivers and cables.
NOTE: Full hinge-up displays are not spared.
This section describes removing components that do not require that you entirely remove the display
assembly from the computer. You can remove the display bezel, webcam/microphone module, and
display panel with the display assembly still attached to the computer.
To remove the remaining display components, including the display brackets, antennas, cable, and
enclosure, you must remove the entire display assembly from the computer. See
Display assembly
and components (whole hinge-up, cable, antennas, hinges, enclosure) on page 89 for more
information about removing the remaining components.
Description Spare part number
Display panels
39.6-cm (15.6-in), HD+, anti-glare, LED, WVA 662395-001
39.6-cm (15.6-in), HD anti-glare, LED, SVA for use in models without WWAN 646978-001
39.6-cm (15.6-in), HD anti-glare, SVA for use in models with WWAN 662393-001
Display bezels
For use in models with a webcam 660276-001
For use in models without a webcam 660277-001
Webcam module 647599-001
Microphone module 647600-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet,
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 41).
Remove the display assembly:
1. Position the computer right-side up with the front toward you.
2. Open the computer as far as possible.
42 Chapter 4 Removal and replacement procedures
