Multiple Instance Spanning-Tree Operation
Troubleshooting an MSTP Configuration
Figure 3-33. Example of show spanning-tree debug-counters instance ports Command Output for One Port
in an MST Instance
Field Descriptions in MSTP Debug Command Output
Table 3-1 contains descriptions of the debugging information displayed in the
output of show spanning-tree debug-counters commands.
Table 3-1. MSTP Debug Command Output: Field Descriptions
HP Switch(config)# show spanning-tree debug-counters instance 2 ports a15
Status and Counters - MSTI Port(s) Debug Counters Information
MST Instance ID : 2
Port : A15
Counter Name Value Last Updated
--------------------------- ---------- -----------------
Starved MSTI MSGs 0
Exceeded Max Hops MSTI MSGs 0
Topology Changes Detected 1 02/09/07 17:40:59
Topology Changes Tx 3 02/09/07 17:41:03
Topology Changes Rx 2 02/09/07 17:41:01
MSTI MSGs Tx 5 02/09/07 17:41:03
MSTI MSGs Rx 173489 02/13/07 18:03:52
Field Description
Invalid BPDUs Number of received BPDUs that failed standard MSTP (802.1Q-REV/D5.0 14.4) validation
checks and were dropped. This counter is maintained by the CIST (default MST instance 0)
on a per-port basis.
Errant BPDUs Number of received BPDUs that were dropped on a port that is configured to not expect
BPDU packets. This counter is maintained by the CIST (default MST instance 0 in the
network) on a per-port basis and is incremented each time a BPDU packet is received on
a port configured with the BPDU filter to ignore incoming BPDU packets (spanning-tree
bpdu-filter command) or the BPDU protection feature to disable the port when BPDU
packets are received (spanning-tree bpdu-protection command).
