HP ProCurve Series 5400zl User Manual

Index – 1
Index
Numerics
100/1000Base-T
connections, length limitations … 2-6
note on cable requirements … B-2
ports, cables used with … 2-6, B-2
twisted-pair cable specifications … B-2
1000Base-LH
connections, length limitations … 2-6
ports, cables used with … 2-6
1000Base-LX
connections, length limitations … 2-6
ports, cables used with … 2-6
1000Base-SX
connections, length limitations … 2-6
ports, cables used with … 2-6
100Base-TX
ports, cables used with … B-2
twisted-pair cable specifications … B-2
10Base-T
ports, cables used with … B-2
twisted-pair cable specifications … B-2
A
Act LED … 1-6
auto MDI/MDI-X operation … B-8, B-10
HP Auto-MDIX feature … B-6
auxiliary or USB port
location on switch … 1-3
B
back of switch
description … 1-9
power connector … 1-9
slot for redundant power supply … 1-9
basic connectivity, example topology … 2-23
basic switch configuration
IP address … 3-3
manager password … 3-3
subnet mask … 3-3
Switch Setup screen … 3-2
battery
replacing battery … 4-7
blinking LEDs
error indications … 5-4
Bootp
automatic switch configuration … 3-2
for in-band console access … 2-20
buttons
Clear button … 1-8
LED Mode Select button … 1-7
Reset button … 1-8
C
cabinet
mounting the switch in … 2-14
note on mounting screws … 2-17
cables
100/1000Base-T
cable specifications … B-2
connections … 2-6
note on cable requirements … B-2
1000Base-LH
connections … 2-6
fiber-optic cable specifications … B-3
1000Base-LX
connections … 2-6
fiber-optic cable specifications … B-3
1000Base-SX
connections … 2-6
fiber-optic cable specifications … B-3
100Base-TX
cable specifications … B-2
10Base-T
cable specifications … B-2
connecting cables to switch ports … 2-19
effects of non-standard cables … 5-1
fiber-optic, specifications … B-3
infrastructure requirements … 2-6
length limitations … 2-6
required types … 2-6
serial for direct console connection … 2-21
