Installing the Series 5400zl Switches
Example Network Topologies
Installing the Series 5400zl
Switches
Example Network Topologies
This section shows a few example network topologies in which the Series
5400zl Switches can be implemented. For more topology information, see the
ProCurve Networking Web site, http://www.procurve.com.
Basic Connectivity
Figure 2-13. Basic Switch Connectivity
The Series 5400zl Switches can provide basic network connectivity to a high
number of PoE devices. These devices can be easily connected, as shown in
the above illustration.
A B
A
C
E F
D
Series 5400zl Switch
Phones, APs and
other
peripherals
