2-16
Installing the Switch
Installation Procedures
Installing the Switch
Note Direct attach cables (DAC) are low-
cost 10-GbE connectivity options
consisting of a one, three, or seven
meter cable with SFP+ connectors
permanently attached to each end.
Caution Use only supported genuine HP ProCurve transceiver accessories with your
switch. Non-ProCurve transceiver accessories are not supported, and their
use may result in product malfunction. Should you require additional
ProCurve transceiver accessories, contact your ProCurve Networking Sales
and Service Office or authorized dealer.
Installing the Mini-GBICs or SFP+ Transceivers:
Hold the mini-GBIC by its sides and gently insert it into any of the mini-GBIC
slots on the switch until the mini-GBIC clicks into place.
Figure 2-12. Installing a Mini-GBIC or SFP
Figure 2-11. One meter DAC
10-GbE
transceiver
