2-22
Installing the Switch
Sample Network Topology
Installing the Switch
Table 2-18. Mapping of RJ-45 to DB-9
Sample Network Topology
An industry standard building block approach requires that applications can
be adapted to a common server environment. Virtualization of these resources
allows for improved scaling, flexibility, and efficient use of resources, while
delivering seamless interoperability.
RJ-45 (Signal reference from
Chassis
DB-9 (Signal reference from PC)
RTS18CTS
TX_Debug 2 6 DSR
TXD 3 2 RXD
GND 4 5 GND
DCD 5 1 DCD
RXD 6 3 TXD
RX_Debug 7 4 DTR
CTS87RTS
9RI
