HP THUNDERBOLT DOCK G4 User Manual

CONTENTS &
NAVIGATION
TECHNICAL WHITE PAPER
Host Specication # of displays on dock Resolution Supported conguration
DP 1.4 DSC Thunderbolt
TM
host 1  1 TB (must be a DSC display) or
1 USB-C® alt mode
1  1 DP
1 (1) 3840 x 2160 @ 60Hz 
2  2 DP or 1 DP + USB-C® alt mode
2 (1)7680 x 4320 @ 60Hz +

1 TB (must be a DSC display)
+ 1 USB-C® Alt mode
1 TB 7680 x 2880 @ 60hz (must be a
DSC display) + 1 DP 5120x2160 @ 60hz
2 (2) 3840 x 2160 @ 60Hz 1 TB + 1 HDMI or
1 TB + 1 USB-C® alt or
1 DP + 1 HDMI or
1 HDMI + USB-C® alt mode
3  (2) 5120x2880@60Hz from DP ports
or DP + USB-C® alt
(1) 5120x2880 @ 60Hz from TB
port (must be a DSC display, if not
TBT port can only support up to
2560x1440@60Hz)
4 
(2) 3840 x 2160 @ 60Hz
(1) 5120x2880 @ 60Hz from DP or
USB-C® Alt mode
(1) 5120x2880 @ 60Hz from TB
port (must be a DSC display, if not,
TBT port can only support up to
2560x1440@60Hz)
(2) 3840 x 2160@ 60Hz from HDMI + DP
or USB Type-C®
*HDMI port can only reach 3840x2160 @ 60Hz.
*HDMI port can only reach 3840x2160 @ 60Hz.
*HDMI port can only reach 3840x2160 @ 60Hz.
*HDMI port can only reach 3840x2160 @ 60Hz.
Host Specication # of displays on dock Resolution Supported conguration
DP 1.4 non-DSC Multifunction
host (High Res enable)
1  1 DP or
1 USB-C® alt mode
2 (2) 3840 x 2160 @ 60Hz 
3 (3) 2560 x 1440 @ 60Hz 
Host Specication # of displays on dock Resolution Supported conguration
DP 1.4 non-DSC Multifunction
host (High Res disabled)
1  1 DP or
1 USB-C® alt mode

2 (2) 2560 x 1600 @ 60Hz 
3 (3) 1920 x 1080 @ 60Hz 
Host Specication # of displays on dock Resolution Supported conguration
DP 1.4 DSC multifunction
mode (High Res Enable)
1  1 USB-C® alt mode
2 (2) 5120 x 2880 @ 60Hz 
(except HDMI port)
3 (3) 3840 x 2160 @ 60Hz 
8.
2
HP Thunderbolt Dock G4 specications summary
HP Thunderbolt G4 Dock, The Dock That
Does It All
3-4
First-time Connection
5-6
Supported Modes (Multi-Function
and Thunderbolt
TM
4/USB4/Thunderbolt
TM
3)
Pre-Boot Support
LED/Power Button
6-9
Charging Support from the Dock
Display Capabilities
9-10
HP Sure Start for Docks
Thunderbolt
TM
Security Levels – Available Functions
and Ports
10-12
Manageability
13-14
Troubleshooting Issues
15-19
Support list for the HP Thunderbolt 4 Dock
HP Commercial Notebook / mWS Platform Support

HP THUNDERBOLT DOCK G4 Specifications

General

Brand	HP
Model	THUNDERBOLT DOCK G4
Category	Docking Station
Language	English
