Setting Up the Monitor

User’s Guide 3–5

Preparing the cantilever-base monitor for wall-mounting

1. Disconnect the power cable and any other cables from the monitor.

2. Remove the monitor base. Refer to “Removing the Monitor Base.” Keep the monitor panel screen down on a flat,

soft area.

3. After the base is removed, remove the rubber plug on the neck of the monitor. You will see a screw below the

rubber plug and two additional screws on the panel.

4. Remove all three screws.

5. Remove the neck from the monitor.

6. Save the removed items (rubber plug, screws, neck, and base) for future use.

7. Follow the instructions included with the mounting fixture to ensure that the monitor is safely attached.

The four-threaded mounting holes that are on the back of the panel are compliant with the VESA standard for

mounting flat-panel monitors. The vp15 monitor uses the 75 mm spacing standard, while the other models use the

100 mm spacing standard.

Use the four holes to attach a swing arm or other mounting fixture.

Other manuals for HP W1907

Questions and Answers:

Need help?

Do you have a question about the HP W1907 and is the answer not in the manual?

General

Pixel pitch	0.285 x 0.285 mm
Display diagonal	19 \
Display resolution	1440 x 900 pixels
Viewable size diagonal	483 mm
Contrast ratio (typical)	1000:1
Digital vertical frequency	55 - 75 Hz
Digital horizontal frequency	30 - 83 kHz
Power requirements	100-240VAC
HDCP	Yes
Certification	FCC Class B
Product color	Silver
Country of origin	China
Market positioning	-
Panel mounting interface	100 x 100 mm
Power consumption (standby)	2 W
Power consumption (typical)	49 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	15 - 90 %
Sustainability certificates	ENERGY STAR
