7 Using HP PC Hardware Diagnostics (UEFI)
HP PC Hardware Diagnostics is a Unied Extensible Firmware Interface (UEFI) that allows you to run diagnostic
tests to determine whether the computer hardware is functioning properly. The tool runs outside the
operating system so that it can isolate hardware failures from issues that are caused by the operating system
or other software components.
When HP PC Hardware Diagnostics UEFI detects a failure that requires hardware replacement, a 24-digit
Failure ID code is generated. This ID code can then be provided to support to help determine how to correct
the problem.
To start HP PC Hardware Diagnostics (UEFI), follow these steps:
1. Start BIOS.
●
Tablets with keyboards
▲ Turn on or restart the computer, quickly press esc.
●
Tablets without keyboards
▲ Turn on or restart the tablet, and then quickly hold down the volume up button.
2. Press or tap f2.
The BIOS searches three places for the diagnostic tools, in the following order:
a. Connected USB drive
NOTE: To download the HP PC Hardware Diagnostics (UEFI) tool to a USB drive, see Downloading
HP PC Hardware Diagnostics (UEFI) to a USB device on page 56.
b. Hard drive
c. BIOS
3. When the diagnostic tool opens, select the type of diagnostic test you want to run, and then follow the
on-screen instructions.
NOTE: To stop a test, press the button you used to access UEFI.
Downloading HP PC Hardware Diagnostics (UEFI) to a USB device
NOTE: The HP PC Hardware Diagnostics (UEFI) download instructions are provided in English only, and you
must use a Windows computer to download and create the HP UEFI support environment because only .exe
les are oered.
There are two options to download HP PC Hardware Diagnostics to a USB device.
Download the latest UEFI version
1. Go to http://www.hp.com/go/techcenter/pcdiags. The HP PC Diagnostics home page is displayed.
2. In the HP PC Hardware Diagnostics section, select the Download link, and then select Run.
56 Chapter 7 Using HP PC Hardware Diagnostics (UEFI)

HP X2 210 G2 Specifications

General

Form factor	Convertible (Detachable)
Product type	Hybrid (2-in-1)
Product color	Silver
Country of origin	China
Stepping	C0
Tjunction	90 °C
Processor cache	2 MB
Processor cores	4
Processor family	Intel Atom®
Processor series	Intel Atom x5 Series
Processor socket	BGA 592
Processor codename	Cherry Trail
Processor frequency	1.44 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	1.84 GHz
Processor operating modes	64-bit
PCI Express configurations	1x1
Scenario Design Power (SDP)	2 W
Maximum number of PCI Express lanes	1
Numeric keypad	No
Pointing device	Touchpad
Full-size keyboard	Yes
Internal memory	2 GB
Internal memory type	DDR3L-SDRAM
Memory layout (slots x size)	1 x 2 GB
Storage media	eMMC
Total storage capacity	32 GB
Compatible memory cards	MicroSD (TransFlash)
Display diagonal	10.1 \
Touch technology	Multi-touch
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Number of execution units	12
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	200 MHz
On-board graphics card dynamic frequency (max)	500 MHz
Battery capacity	32.5 Wh
Number of battery cells	2
AC adapter power	45 W
Audio decoders	DTS Studio Sound
Rear camera resolution (numeric)	5 MP
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Sustainability certificates	EPEAT Silver, ENERGY STAR
Processor code	SR29Z
Processor ARK ID	87383
Processor package size	17 x 17 mm
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	170 mm
Width	265 mm
Height	16.2 mm
Weight	1090 g
Height (tablet mode)	9.2 mm
Weight (tablet mode)	580 g
