HP Z27n User Manual

QuickSpecs
HP Z27n 27-inch Narrow Bezel IPS Display
Technical Specifications
c04675159 — 15272 — Worldwide — Version 1 — May 18, 2015
Page 4
1280 x 1024 @ 60 Hz
1366 x 768 @ 60 Hz
1440 x 900 @ 60 Hz
1600 x 900 @ 60 Hz
1600 x 1200 @ 60 Hz
1680 x 1050 @ 60 Hz
1920 x 1080 @ 60 Hz
1920 x 1200 @ 60 Hz
2560 x 1440 @ 60 Hz
Maximum Pixel Clock
Speed
250 MHz(DVI, DP, HDMI); 150 MHz (MHL)
Anti-Glare
Yes
Video/Other
Inputs
Plug and Play
Yes
Input/Output
Connectors
(1) DVI-Dual Link
(1) MHL 2.0
1
/HDMI 1.4
(1) DisplayPort 1.2 In, (1) DisplayPort 1.2 Out
(1) Mini DisplayPort In
HDCP support on all inputs
USB
4 USB 3.0 [4 downstream (one fast charging), 1 upstream]
Video Cables Included
(1) DisplayPort 1,8 m (5.9 ft) (1) Mini-DisplayPort 1,8 m (5.9 ft)
(1) USB 3.0 1,8 m (5.9 ft)
Audio
(1) 3.5 mm audio-out connects headphones or HP speaker bar*
*Sold separately.
Multimedia
Speakers
N/A
Power
Power Supply
Internal
Input Power
100 - 240 VAC 50/60 Hz
Maximum Power
83 W
Typical Power
47 W
Sleep Power
0.5W (standby)
Power Cable Length
1,8 m (5.9 ft)
Mechanical
Dimensions
(W × D × H)
Unpacked w/stand
61,43 x 21,82 x 53,37 cm
24.2 x 8.6 x 21.0 in
(max height)
61,43 x 21,82 x 40,37 cm
24.2 x 8.6 x 15.9 in
(min height)
Unpacked w/o stand
(head only)
61,43 x 5,39 x 36,41 cm
(24.2 x 2.1 x 14.3 in)
Packaged
73,1 x 28,5 x 47,9 cm
(28.8 x 11.2 x 18.9 in)
Weight
Head Only
5,1 kg (11.16 lb)
Unpacked
7,66 kg (16.89 lb)
Packaged
10 kg (22.1 lb)

HP Z27n Specifications

General

3D	No
HD type	2K Ultra HD
Pixel pitch	0.2331 x 0.2331 mm
Aspect ratio	16:9
Response time	14 ms
Display surface	Matt
Display diagonal	27 \
Display technology	LED
Vertical scan range	50 - 60 Hz
Horizontal scan range	30 - 90 kHz
Viewable size diagonal	335.66 mm
Viewable size, vertical	596.74 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1600 x 900, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1366 x 768, 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switch	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DVI-D ports quantity	1
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Product color	Black
Country of origin	China
Market positioning	Business
Pivot angle	0 - 90 °
Tilt angle range	-5 - 22 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power consumption (max)	83 W
Annual energy consumption	55 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	47 W
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	18.2 mm
Height (with stand)	533.7 mm
Depth (without stand)	53.9 mm
Width (without stand)	614.3 mm
Height (without stand)	364.1 mm
Weight (without stand)	7660 g
