HP Z27n User Manual

QuickSpecs
HP Z27n 27-inch Narrow Bezel IPS Display
Environmental Data
c04675159 — 15272 — Worldwide — Version 1 — May 18, 2015
Page 6
Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the following approvals and
may be labeled with one or more of these marks:
 IT ECO declaration
 US ENERGY STAR®
 TCO 6.0
 EPEAT® <Gold> registered in the United States. See http://www.epeat.net for
registration status in your country
Energy Consumption
(in accordance with US
ENERGY STAR® test method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation
28.2 W
27.9 W
28.4 W
Sleep
0.5 W
0.5 W
0.5 W
Off
0.5 W
0.4 W
0.4 W
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation
96 BTU/hr
95 BTU/hr
97 BTU/hr
Sleep
2 BTU/hr
2 BTU/hr
2 BTU/hr
Off
2 BTU/hr
1 BTU/hr
1 BTU/hr
*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level
is attained for one hour.
Additional Information
 This product is in compliance with the Restrictions of Hazardous Substances (RoHS)
directive - 2002/95/EC.
 This HP product is designed to comply with the Waste Electrical and Electronic
Equipment (WEEE) Directive – 2002/96/EC.
 This product is in compliance with California Proposition 65 (State of California; Safe
Drinking Water and Toxic Enforcement Act of 1986).
 This product is in compliance with the IEEE 1680 (EPEAT) standard at the Gold level,
see www.epeat.net
 Plastics parts weighing over 25 grams used in the product are marked per ISO 11469
and ISO1043.
 This product contains 37.5 % post-consumer recycled plastic (by wt.)
 This product is 97.6 % recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Corrugated
1308 g
Internal:
PLASTIC/EPS (Expanded Polystyrene)
517 g
PLASTIC/EPE-Expanded Polyethylene
56.4 g
RoHS Compliance
Hewlett-Packard is committed to compliance with all applicable environmental laws and
regulations, including the European Union Restriction of Hazardous Substances (RoHS)
Directive. HP’s goal is to exceed compliance obligations by meeting the requirements of the
RoHS Directive on a worldwide basis. By July 1, 2006, RoHS substances will be virtually
eliminated (virtually = to levels below legal limits) for all HP electronic products subject to the
RoHS Directive, except where it is widely recognized that there is no technically feasible
alternative (as indicated by an exemption under the EU RoHS Directive).

HP Z27n Specifications

General

3D	No
HD type	2K Ultra HD
Pixel pitch	0.2331 x 0.2331 mm
Aspect ratio	16:9
Response time	14 ms
Display surface	Matt
Display diagonal	27 \
Display technology	LED
Vertical scan range	50 - 60 Hz
Horizontal scan range	30 - 90 kHz
Viewable size diagonal	335.66 mm
Viewable size, vertical	596.74 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1600 x 900, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1366 x 768, 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switch	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DVI-D ports quantity	1
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Product color	Black
Country of origin	China
Market positioning	Business
Pivot angle	0 - 90 °
Tilt angle range	-5 - 22 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power consumption (max)	83 W
Annual energy consumption	55 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	47 W
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	18.2 mm
Height (with stand)	533.7 mm
Depth (without stand)	53.9 mm
Width (without stand)	614.3 mm
Height (without stand)	364.1 mm
Weight (without stand)	7660 g
