HP Z38c Maintenance And Service Guide

11
How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare part number
Manufacturer part number
Z38c
M74280-001
ADPCG2015AB3
Z38c
M74280-002
ADPCG2015AC3
Capacitors and connectors are available for purchase from the following EU distributors:
 Farnell: Farnell UK - Electronic Components Distributor
 RS Component: Capacitors | RS Components (rs-online.com)
 DK : https://www.digikey.com/
Capacitors by distributor
Component
description
Location
Component
distributor
Distributor part
number
Capacitor 470uF 20%
25V 10*12 2000hr
1490mA
C9218 and C952
Farmell
A750MS477M1EAAE015
470uF 20% 25V 10*12
5000hr 1600mA
C9216,C9217,C9222,C954
RS
EEUFR1E471
Connectors by manufacturer
Component
description
Location identifier
Component distributor
Distributer part
number
HDMI
J2
DK
A35071TR-ND
A35071CT-ND
16
Z38C WALL MOUNT ASS'Y
1
17
Z38C REAR COVER
1
18
Z38C KEY PCB
1
19
Z38C KEY
1
20
Z38C STAND
1
21
Z38C LENS
1
S1
SCREW M3L4-I
38
S2
SCREW M4
1
S3
SCREW M3L6
12
S4
STEP SCREW-M3
2
S5
SCREW M4L10-I
4
S6
SCREW Q3L3
2

HP Z38c Specifications

General

3D	No
HD type	UltraWide Quad HD+
Pixel pitch	0.22908 x 0.22908 mm
Display diagonal	37.5 \
Display resolution	3840 x 1600 pixels
Display technology	LED
Native aspect ratio	21:9
Viewable size, vertical	366.5 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	879.6 mm
Digital vertical frequency	24 - 76 Hz
Digital horizontal frequency	27 - 130 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1600 x 900, 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 1920 x 1600, 2560 x 1080, 2560 x 1600 (WQXGA)
On/off switch	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-C
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	3
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	195 W
Annual energy consumption	93 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	80 W
Product color	Black
Country of origin	China
Market positioning	Business
Tilt angle range	-5 - 20 °
Number of OSD languages	10
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR

Weight and Dimensions

Depth (with stand)	248 mm
Height (with stand)	558.7 mm
Weight (with stand)	13800 g
Depth (without stand)	104.2 mm
Width (without stand)	895.5 mm
Height (without stand)	399.5 mm
Weight (without stand)	9800 g
