Component Function
7 VGA Connector Connects the VGA cable to the monitor
8 USB Upstream Connector Connects the monitor USB hub cable to a host USB port/
hub.
9 USB Downstream Connectors Connects optional USB devices to the monitor.
10 Information Card Provides information needed for a support call.
11 USB Downstream Connectors
(side panel)
Connects optional USB devices to the monitor.
ZR2440w Model
Figure 3-5 ZR2440w Rear Components
Component Function
1 Cable Lock Provision Provides slot for use with cable security locks.
2 Master Power Switch Turns off all power to the monitor.
ENWW
Rear Components
9
