Procedure 1. Connect the power supply to the server.
Observe the Power indicator on the front
panel, and record its status and color.
Check whether each PSU has indicators,
and record the status and color of each
PSU indicator.
2. Press the power button to power on the
server. Observe the Power indicator, and
record its status and color changes.
Observe the indicators of the hard disks,
network interface cards (NICs), and host
bus adapters (HBAs), and record their
status and color changes.
3. Remove a power cable from a PSU to
simulate a PSU hardware error. Observe
the PSU indicator, and record its status
and color changes.
Expected Results 1. The server components have status
indicators, and the status indicators
function properly.
2. The PSU indicator correctly indicates the
PSU hardware error.
Test Result
Remarks
4.2.2 Testing the Fault Diagnosis LED
Case No.
4.2.2
Test Objective To verify that:
1. The fault diagnosis LED is available on
the front panel.
2. The fault diagnosis LED can correctly
indicate a server hardware or system
error code.
Test Networking Diagram See section 2.1 Network Diagram.
Prerequisites The server is powered on.
5288 V5 Server
Acceptance Guide
4 Test Cases and Records
Issue 03 (2019-03-25) Copyright © Huawei Technologies Co., Ltd. 13
