Technical Manual
Airbridge BTS3606A CDMA Base Station
System Description
Chapter 3 Product Architecture
3-3
Acronyms Full name
CCPM Compact-BTS Channel Process Module
CECM Compact-BTS EVDO Channel Module
CDDU Compact-BTS Dual Duplexer Unit
CHPA Compact-BTS High power Amplifier
CPCM Compact-BTS Power Combination Module
CTRM Compact-BTS Transceiver Module
CMTR Compact-BTS Multi-carrier Transceiver Module
CMPA Compact-BTS Multi-carrier Power Amplifier
PSUAC/DC AC/DC Power Supply Unit
PSUDC/DC DC/DC Power Supply Unit
PMU Power Management Unit
&
Note:
l The BTS3606A adopts the CCPM to support CDMA2000 1x, and the CECM to support 1xEV-DO.
l The same BTS3606A cabinet can be configured with CCPM and CECM, that is, the BTS3606A can
simultaneously support CDMA2000 1x and 1xEV-DO.
l The CPCM supports the power combination when the BTS3606 operates at 1900 MHz.
l CTRM and CHPA support the multi-carrier application.
3.3 System Structure
The BTS3606A system consists of baseband subsystem, Radio Frequency (RF)
subsystem, power supply subsystem, and antenna subsystem.
Space is also reserved in the BTS3606A cabinet to hold the transmission equipment
such as the micro wave equipment and SDH equipment to support flexible
transmission access mode.
Figure 3-3 shows the structure of the BTS3606A.
