Technical Manual
Airbridge BTS3606A CDMA Base Station
System Description
Chapter 7 Technical Specifications
7-5
II. Receiver specifications
Working band 1850 MHz to 1910 MHz
Channel bandwidth 1.23 MHz
Channel precision 50 kHz
Sensitivity of signal
receiver
Single-carrier: Better than -127 dBm (RC3, main and diversity receiving)
Multi-carrier: Better than -126 dBm (RC3, main and diversity receiving)
7.4 Specifications for ODU3601C Cascading
The following lists the related specifications when the BTS3606A connects to the
ODU3601C.
Maximum distance of single cascading
10 km, 70 km (corresponding to two
types of CCPM)
Maximum number of cascading levels 3
CDMA2000 1x
Maximum total distance after cascading 90 km
Maximum distance of single cascading 10 km
Maximum number of cascading levels 3 1xEV-DO
Maximum total distance after cascading 10 km
