Huawei B315 User Manual

3
USB port
Connect to a USB device.
This port cannot be connected to USB host devices
such as computers.
The B315 supports USB 1.0/USB 2.0 storage devices in
FAT32 format of up to 32 GB. Storage devices with
power supply requirements exceeding USB standards
may not work properly. It is recommended that you
provide an external power supply in these cases.
The B315 is compatible with samba-supported USB
printers.
Telephone port Connect to a telephone/Analogue FAX machine
2 Installation
Scenario 1: Accessing the Internet using an LTE, 3G, or
2G network
Step 1: Installing the SIM card
1. Slide off the card slot cover.
2. Insert the SIM card into the card slot. Ensure that the beveled edge of the SIM card
aligns with that of the card slot.
3. Close the card slot cover.

Huawei B315 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	150 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
4G standard	LTE
2G standards	GSM
3G standards	UMTS
Product type	Tabletop router
Product color	White
Power source type	AC

Weight and Dimensions

Depth	46 mm
Width	139 mm
Height	186 mm
Weight	275 g
