Huawei B315 User Manual

6
Optional: Adding a printer
1. Install the printer's driver in your computer, and then connect the computer and the
B315 via wired way or Wi-Fi way.
2. Connect printer to the B315 with USB cable and then power on them.
3. Log in to web management page, and choose Settings > Advanced > Storage
Services.
4. Check the Enable samba, and click Apply.
5. Click Add, to configure the parameters as follows.
 User name/Password: Follow the page to enter username and password. When
accessing Samba, you need to input these parameters to login.
 Right: Select Read only or Read/Write.
 Directory: Click Browse and select the root directory of the printer.
6. Choose Start > Run, enter the default IP address of the B315: http://192.168.8.1,
and then press Enter.
7. In the shown dialog box, enter the username and password you have configured on
the Storage Services page to access to the Samba service.
8. Double click the printer icon in the window, follow the wizard and select the
corresponding printer driver to add a printer. Wait a few minutes for the settings to
take affect.
9. Check the status of printer from Control Panel, printer window. Status should be
shown ready. Now you can use the printer.

Take a computer with Windows 7 operating system as an example.

If the external USB printer cannot be used, please consult the printer manufacturer
whether this method is supported.

Huawei B315 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	150 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
4G standard	LTE
2G standards	GSM
3G standards	UMTS
Product type	Tabletop router
Product color	White
Power source type	AC

Weight and Dimensions

Depth	46 mm
Width	139 mm
Height	186 mm
Weight	275 g
