Huawei BTS3900C User Manual

7.1 List of BTS3900C Cables
The BTS3900C cables are the PGND cables, power cables, transmission cables, CPRI cables,
signal cables, and RF cables.
PGND Cables
PGND cables need to be installed onsite. Table 7-1 lists the cable connections.
Table 7-1 PGND cables
Cable One End The Other End
Connector Installation
Position
Connector Installation Position
OMB PGND
cable
OT terminal Ground bar at the
bottom of the
OMB
OT terminal Ground bar outside the
cabinet
RRU PGND
Cable
OT terminal Ground terminal
on the RRU
OT terminal Ground bar outside the
cabinet
Power Cables
Table 7-2 and Table 7-3 list the power cables used in an AC cabinet. Table 7-4 and Table
7-5 list the power cables used in a DC cabinet.
Table 7-2 Power cables installed before delivery (in an AC cabinet)
Cable
One End The Other End
Connector Installation
Position
Connector Installation
Position
7.5.3 ETP48100-
A1 Power Cable
OT terminal L/L1 and N/L2
on the INPUT
side of the
ETP48100-A1
Cord end
terminal
L/N, N/L, PE on
the AC surge
protection box
OT terminal PDU10D-01
7.5.6 HEUB
Power Cable
EPC4 or
EPC6
connector
LOAD9 on the
PDU10D-01
3V3 connector DC INPUT on
the HEUB
BTS3900C (Ver.C)
Hardware Description 7 BTS3900C Cables
Issue 03 (2013-05-27) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
122
