About This Document
This document describes the functions, specifications, and configurations of the components in
the BTS3900C (Ver.C) cabinet as well as cable types, cable connections, and connector
specifications. This document serves as a reference for the BTS3900C (Ver.C) site planning and
deployment. BTS3900C (Ver.C) is shortened to BTS3900C in this document.
Product Version
The following table lists the product versions related to this document.
Product Name Product Version
BTS3900C V100R007C00
BTS3900C WCDMA V200R014C00
Intended Audience
This document is intended for:
l System engineers
l Base station installation personnel
l Site maintenance personnel
Organization
1 Changes In BTS3900C (Ver.C) Hardware Description
This chapter describes the changes in the BTS3900C (Ver.C) Hardware Description.
2 BTS3900C Cabinet
This chapter describes the exterior, boards, modules, and configurations of the BTS3900C
cabinets, providing reference for planning and deploying the BTS3900C.
3 BTS3900C Modules
This chapter describes the modules in the BTS3900C, including the BBU, RRU, and GPS surge
protector.
BTS3900C (Ver.C)
Hardware Description About This Document
Issue 03 (2013-05-27) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii
