20
Indicator Status Description
Blinking The HG630 is working in routing mode.
Data is being transmitted.
Off The HG630 is working in bridge mode.
The HG630 is powered off.
WLAN On
The WLAN connection is set up, but no data is
being transmitted.
Blinking
The WLAN connection is set up, and data is
being transmitted.
Off The WLAN function is disabled.
WPS Blinking
A wireless client, such as a computer
installed with a wireless network adapter, is
connecting to the HG630 using the WPS
function.
This process lasts for no longer than 120
seconds.
Off The WPS function is disabled or faulty.
LAN1 ~
LAN4
On The HG630 is connected to a device properly.
Blinking
Data is being transmitted between the HG630
and the device connected.
Off No connection is set up on the port.
