Huawei HG630 User Manual

19
7 Appendix
7.1 Indicators
Indicator Status Description
Power On The HG630 is powered on.
Off The HG630 is powered off or faulty.
DSL Blinking The HG630 is being activated through DSL.
Steady on The HG630 is activated through DSL.
Off  The HG630 is powered off.
 The DSL port is not connected.
Internet On  The HG630 is working in routing mode.
 No data is being transmitted.

Huawei HG630 Specifications

General

Wi-Fi Standard	802.11b/g/n
Frequency Band	2.4 GHz
LAN Ports	4
WAN Port	1 x RJ-11
Wireless Speed	300 Mbps
WLAN	Yes
Firewall	Yes
Ports	4 x LAN, 1 x WAN, 1 x USB
Wi-Fi	Yes
VDSL2 Support	Yes
ADSL2+ Support	Yes
VoIP	No
Security	WPA/WPA2
LAN Port Type	Ethernet
Type	Wireless
Device Type	Wireless Router
