1. Click OK.
The Execution Result dialog box is displayed indicating that the operation succeeded.
2. Click Close.
----End
4.5.5 Creating a Logical Port
This operation enables you to create a logical port for managing and accessing file based on
Ethernet ports, bond ports, or VLANs.
Precautions
The number of logical ports created for each controller is recommended not more than 64. If
the number exceeds 64 and a large number of ports do not work properly, logical ports drift
towards the small number of ports available. As a result, service performance deteriorates.
Procedure
Step 1 Log in to DeviceManager.
Step 2 Choose vStore.
Step 3 In the vStore view, click
or to select the vStore for which a user is to be created.
Step 4 At the lower-right of the vStore view, click Details.
The vStore view is displayed.
Step 5 Choose Provisioning > Port and click Create.
The Create Logical Port dialog box is displayed.
Step 6 In the Create Logical Port dialog box, configure related parameters.
Table 4-16 describes related parameters.
OceanStor V3 Series
HyperMetro Feature Guide for File
4 Configuration
Issue 05 (2018-01-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
110
