Huawei P9 LITE User Manual

Getting Started
35
By default, screenshots are saved to the Screenshots folder in Gallery .
Notifications
Status indicator
The status indicator changes color and flashes to indicate the following:
• Steady red (not charging): The battery level is critically low and the phone will turn off
automatically.
• Steady red (when charging): The battery level is critically low.
• Steady yellow (when charging): The battery level is medium.
• Steady green (when charging): The battery is almost full or already full. Unplug the
charger when the battery level reaches 100%.
• Flashing green (not charging): You have unread messages, notifications, or missed
calls.

Huawei P9 LITE Specifications

General

Display diagonal	5.2 \
Orientation sensor	-
Audio formats supported	AAC, AMR, AWB, FLAC, MID, MP3, MP4, OGG, WAV
Video formats supported	3GP, MKV, MP4, WEBM
Processor cores	4
Processor family	Hi-Silicon
Processor frequency	2 GHz
Coprocessor frequency	1.7 GHz
Processor lithography	16 nm
Coprocessor architecture	ARM Cortex-A53
RAM capacity	3 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Internal storage capacity	16 GB
Flash type	LED
Front camera type	Single camera
Rear camera resolution (numeric)	13 MP
Front camera resolution (numeric)	8 MP
Battery capacity	3000 mAh
2G standards	GSM
3G standards	UMTS
SIM card type	NanoSIM
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
3G bands supported	900, 1900, 2100 MHz
SIM card capability	Single SIM
2G bands (primary SIM)	850, 900, 1800, 1900 MHz
Mobile network generation	4G
Graphics card	Mali T830
Graphics & IMC lithography	28 nm
USB connector type	Micro-USB
HDMI ports quantity	0
Headphone connectivity	3.5 mm
Form factor	Bar
Product color	White
Platform	Android
Operating system installed	Android 6.0
Storage temperature (T-T)	-20 - 45 °C
Operating temperature (T-T)	0 - 35 °C
Cables included	USB

Weight and Dimensions

Depth	7.5 mm
Width	72.6 mm
Height	146.8 mm
Weight	147 g
