Huawei Quidway S5000 Series Operation Manual

Operation Manual - QoS/ACL
Quidway S5000 Series Ethernet Switches Chapter 2 QoS configuration
2-5
z Set queue scheduling
z Set traffic mirroring
z Set traffic statistics
You should first define an ACL before performing those QoS configurations. When the
ACL is enabled, packet filtering is available.
2.2.1 Setting Priority Level
The following commands are involved in setting priority level on a port. The switch
replaces the packets’ 802.1p priority label with the port priority, for purpose of QoS
control.
Please perform the following configurations in Ethernet port view.
Table 2-1 Setting priority level
Operation Command
Set priority level s priority priority-level
Restore the default priority levels undo priority
Eight priority levels can be set on the port of the switch as needed.
priority-level ranges from 0 to 7. By default, the port is at priority level 0.
2.2.2 Setting Traffic Limit
Traffic limit refers to rate limit based on traffic. If the traffic threshold is exceeded,
corresponding measures will be taken, for example, dropping the excessive packets or
re-defining their priority levels.
The following commands are involved in configuring traffic limit.
Please perform the following configurations in Ethernet port view. .
Table 2-2 Setting traffic limit
Operation Command
Set traffic limit
traffic-limit inbound { ip-group
{
acl-number | acl-name } [ rule rule ] | link-group
{
acl-number | acl-name } [ rule rule ] }* target-rate [ exceed action ]
Remove traffic limit
undo traffic-limit inbound { ip-group
{
acl-number | acl-name } [ rule rule ] |
link-group
{
acl-number | acl-name } [ rule rule ] }*
You should first define an ACL before performing this configuration task.
