4.4 Replacing a Non-Blade RRU with a Blade RRU
This section describes the procedure and precautions for replacing a non-blade RRU with a
blade RRU.
Prerequisites

The operations in 4.1 Preparations Before Replacement have been performed.

The following tools and materials are available: ESD gloves, Phillips screwdrivers (M3
to M6), an M6 inner hexagon torque screwdriver, waterproof tape, and PVC insulation
tape.

The number and type of RRUs to be replaced are confirmed, and new RRUs are
available.
Context

RRUs and attachment plates in this section are only for reference. The actual RRUs and
attachment plates may be different.

Table 4-1 shows the installation of the mounting kits and conversion bracket when
non-blade RRUs are assembled. When non-blade RRUs are not assembled, the mounting
kits and conversion bracket for blade RRUs are required for assist subsequent capacity
expansion, as shown in Table 4-1.
Table 4-1 Mounting kits and conversion bracket used for replacing non-blade RRUs with blade
RRUs
Replacement
Scenario
Position of the
RRU to be
Replaced
Mounting Kit
Reused or Not
Conversion
Bracket Reused or
Not
Non-blade RRUs are
assembled.
Middle
Reused
(Recommended)
Reused
For details about
how to install blade
RRUs, see
(Recommended)
Method 1: Reuse the
conversion bracket
Reused
Not reused
For details about
how to install blade
RRUs, see Method
2: The conversion
bracket is not reused
At bot sides
Not reused
Not reused
For details about
how to install blade
RRUs, see Replace
the RRUs at the two
sides
