Context
A pole supports three, four, or six RRUs. The procedures for installing them are the same. The
following provides an example for the procedure of installing four RRUs on a pole.
NOTICE:
RRUs can be stacked only when installed on one or more poles, and a maximum of three RRUs can
be stacked.
Procedure
1. Install two RRUs, as shown in Figure 1. For details, see Installing Two RRUs.
Figure 1 Two RRUs installed on a pole
2. Use an M6 inner hexagon screwdriver to loosen the four hex socket screws from the main
bracket and pole mounting kit on the second set of mounting kits, and remove the main bracket,
as shown in Figure 2.
