Huawei SUN2000-36KTL User Manual

SUN2000-(33KTL-A, 36KTL, 42KTL)
User Manual
7 Man-Machine Interactions
Issue 07 (2018-05-04)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
87

SUN2000_Master_Release.bin

SUN2000_Slave_Release.bin

update.sh

vercfg.xml

When the login password of the SUN2000 APP is the initial password (00000a), there is
no need to perform Step 3–Step 5.

When the login password of the SUN2000 APP is not the initial password, perform Step
3–Step 7.
Step 3 On the SUN2000 APP, tap Inverter Command Settings to generate a boot script file. For
details, see the SUN2000 APP User Manual.
Step 4 Import the boot script file to a PC.
Step 5 Replace the boot script file in the upgrade package with the one generated by the SUN2000
APP.
Step 6 Copy the extracted files to the root directory of the USB flash drive.
Step 7 Connect the USB flash drive to the USB port. The system automatically identifies the USB
flash drive and executes all commands specified in the boot script file. View the LED
indicator to determine the operating status.
Verify that the ciphertext in the boot script file matches the login password of the SUN2000
APP. If they do not match and you insert the USB flash drive for five consecutive times, the
user account will be locked for 10 minutes.
Table 7-5 LED indicator description
LED Indicator
Status
Meaning
Green off
There is no operation with
a USB flash drive.
Blinking green at long intervals (on
for 1s and then off for 1s)
There is an operation with
a USB flash drive.
Blinking green at short intervals (on
for 0.125s and then off for 0.125s)
An operation with a USB
flash drive has failed.
Steady green
An operation with a USB
flash drive is successful.

Huawei SUN2000-36KTL Specifications

General

Purpose	Solar panel
Efficiency	98.8 %
Output power	36000 W
Weatherproof	Yes
Certification	EN 62109-1/-2, IEC 62109-1/-2, EN 50530, IEC 62116, IEC 60068, IEC 61683
Input voltage	250 - 1100 V
Output voltage	220/380, 230/400, 277/480 V
Input frequency	- Hz
Power supply type	Outdoor
Power current type	DC-to-AC
Adjustable output voltage	-
Power protection features	Over current
International Protection (IP) code	IP65
Product color	White
Quantity per pack	1 pc(s)
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	0 - 100 %

Weight and Dimensions

Depth	283 mm
Width	930 mm
Height	550 mm
Weight	62000 g
