5 Setting Control Panel
5.1 LCD Panel
The UPS control panel is located on the front panel of the chassis. The control
panel allows you to control and operate the UPS, view the running status, set
parameters, and view alarms.
Figure 5-1 LCD panel
Table 5-1 Icon description
Icon
Function
Backup time information
UPS2000-A-(1 kVA-3 kVA)
User Manual 5 Setting Control Panel
Issue 17 (2024-01-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 44
