ATTACHING SOLENOIDS
The SVC-100 is provided with a solenoid attached to
the controller. The SVC-200 and SVC-400 multi-station
controllers will operate up to 2 or 4 solenoids, respectively.
Hunter DC solenoids (P/N 458200) can easily be installed
on all Hunter Plastic Valves. For the SVC-200 & SVC-400,
solenoids must be ordered separately.
NOTE: Must use DC Latching Solenoids.
24VAC Solenoids will not operate with
the SVC.
To Wire DC Solenoids to the SVC
1. Attach the black leads from each solenoid to the single
common wire (black lead) coming from the SVC. Secure
all wire connections with waterproof connectors.
2. Attach one red wire from each solenoid to the cor-
responding station wire (red lead) from the SVC. The
station numbers are identified on the face of the SVC.
Secure all wire connections with waterproof connectors.
NOTE: The maximum wire distance between
the solenoid and SVC is 100 feet (18 gauge
minimum wire size).
The SVC can also operate non-Hunter DC latching sole-
noids. Below is a list of SVC compatible solenoids.
Model Solenoid
Baccara G75-0-1002
Bermad S392-2
Nelson 8090
Rain Bird TBOSPSOL
Station Wire (Red Leads)
Common Wire (Black Leads)
